Filtration grade: 5µm
Port Size: 1/2" G
Auto drain: N.O. (drain port is open when pressure is not applied)
Pressure gauge: Square embedded type pressure gauge (with limit indicator)
Bowl: Polycarbonate
Drain port: With drain cock
Exhaust mechanism: Relieving type
Standard set pressure: 0,05 - 0,85MPa
Related products
AR43P-260S
Set nut
AR43P-270AS
Bracket Assembly
Specifications
| Brand | SMC |
| Connection pressure gauge | Integrated |
| Bowl | Polycarbonate |
| Filter (micron) | 5 |
| Airconnection | 1/2" |
| Airpress max. (MPa) | 1 |
| Mountingbrackets | AR43P-270AS |
| Mountingnuts | AR43P-260S |
| (Nl/min) | 1900 |
| Workingpressure (MPa) | 0,05 - 0,85 |
| Sound standard | 1/2" |
| EAN | 8717981338238 |
